Kubota KX71-2 Specifications
|
|
|
Specifications
|
|
|
|
|
|
Model
|
|
|
|
KX71-2Ľa
|
|
Machine weight
|
|
Cabin
|
Kg
|
2,980
|
|
(rubber shoe type)
|
|
|
|
|
|
|
|
Canopy
|
Kg
|
2,810
|
|
Bucket capacity, std. SAE/CECE
|
|
m3
|
0.07
|
|
Bucket
|
with side teeth
|
mm
|
506
|
|
width
|
without side teeth
|
mm
|
480
|
|
Engine
|
Model
|
|
|
D1505-EBH-8
|
|
|
Type
|
|
|
Water-cooled, diesel engine
|
|
|
|
|
|
E-TVCS (Economical, ecological type)
|
|
|
Output ISO9249
|
PS/rpm
|
30/2,600 (29/2,600)
|
|
|
|
|
kW/rpm
|
22.1/2,600 (21.3/2,600)
|
|
|
Number of cylinders
|
|
4
|
|
|
Bore x stroke
|
mm
|
78.0 x 78.4
|
|
|
Displacement
|
cc
|
1,498
|
|
Overall length
|
|
|
mm
|
4,565
|
|
Overall height
|
Cabin
|
|
mm
|
2,445
|
|
|
Canopy
|
|
mm
|
2,345
|
|
Swivelling speed
|
|
|
rpm
|
8,7
|
|
Rubber shoe width
|
|
|
mm
|
300
|
|
Tumbler distance
|
|
|
mm
|
1,485
|
|
Dozer size (width x height)
|
|
|
mm
|
1,500 x 324
|
|
Hydraulic pilot lever
|
|
|
|
Standard
|
|
Straight level mechanism
|
|
|
|
Standard
|
|
Hydraulic Pumps
|
P1, P2
|
|
|
Gear type
|
|
|
Flow rate
|
|
ltr/min
|
28.6
|
|
|
Hydraulic pressure
|
MPa(kgf/ cm2)
|
19.6(200)
|
|
|
P3
|
|
|
Gear type
|
|
|
Flow Rate
|
|
ltr/min
|
18.2
|
|
|
Hydraulic pressure
|
MPa(kgf/ cm2)
|
15.7(160)
|
|
Max. digging force
|
|
Arm
|
kN(kgf)
|
14.7(1,500)
|
|
|
|
Bucket
|
kN(kgf)
|
24.6(2,520)
|
|
Boom swing angle (left/right)
|
|
|
deg
|
90/50
|
|
Auxilary circuit
|
Flow Rate
|
|
|
46.8
|
|
|
Pressure
|
|
MPa(kgf/ cm2)
|
19.6(200)
|
|
Hydraulic reservoir
|
|
|
ltr
|
80
|
|
Fuel tank capacity
|
|
|
ltr
|
63
|
|
Max. traveling speed
|
Low
|
|
km/h
|
2.1
|
|
|
High
|
|
km/h
|
4
|
|
Ground contact pressure
|
With cabin
|
|
kPa(kgf/c m2)
|
29 (0.29)
|
|
(rubber shoe type)
|
With canopy
|
kPa(kgf/c m2)
|
28 (0.28)
|
|
Ground clearance
|
|
|
mm
|
315
|
|
* Specifications are subject to change without notice for the purpose of improvement. Working Range
|
|
|
|
|
|
|
|
Lifting Capacity
|
|
|
|
|
|
Model
|
|
|
Standard Arm
|
Long Arm
|
|
Arm length
|
|
|
1,200 mm
|
1,400 mm
|
|
A
|
Max. digging height
|
4,660 mm
|
4,845 mm
|
|
B
|
Max. digging height
|
3,365 mm
|
3,530 mm
|
|
C
|
Max. digging depth
|
2,680 mm
|
2,875 mm
|
|
D
|
Max. vertical digging depth
|
2,065 mm
|
2,245 mm
|
|
E
|
Digging radius
|
Max. extension
|
4,525 mm
|
4,845 mm
|
|
F
|
Max. Digging radius
|
at ground level
|
4,395 mm
|
4,715 mm
|
|
G
|
Min. swing radius
|
without boom swing
|
1,670 mm
|
1,710 mm
|
|
|
of boom
|
with boom swing
|
1,285 mm
|
1,325 mm
|
|
Rear swivelling radius
|
|
|
1,375 mm
|
1,375 mm
|
|
|
